Covers Most of the Digital Audio Media Available Today
|
SACD (Single/Hybrid 2ch) CD Playback Network Supports to High-res Digital Audio Files Including MQA MQA-CD Playback Chromecast Built-in / Works with Google Assistant Spotify Connect TIDAL DEEZER Internet Radio Airplay2 Bluetooth Amazon Music Qobuz
|
|
Grand Class High-quality Sound
|
High-speed switching power supply High-performance D/A converter ESS ES9026PRO, and Dual Mono Construction D/A Circuit, Variable Analog Audio Output Proprietary discrete amplifier circuit Battery Driven Clock Generator Pure Disc Mode for SACD/CD Playback for Greater Sound Purity Supports Higher Grade Headphone Connection with Integrated Class AA Headphone AMP High-Res Re-master
|
|
High-quality Technics Design
|
Four-Section Configuration High-Rigidity Chassis and Aluminium Die-cast Disc Tray – High-Stability SACD Mechanism 7mm Thick Aluminium Plate Used for the Front Panel Control Port for System Control with SU-G700
|
|
Disc Compatibility
|
Super Audio CD (2 ch area only), CD, CD-R, CD-RW
|
|
Disc Format
|
Super Audio CD, CD-DA
|
|
Frequency Response
|
Super Audio CD: 2 Hz to 50 kHz (-3 dB) / CD: 2Hz to 20 kHz (-3 dB)
|
|
Dynamic Range (IHF-A)
|
Super Audio CD: BALANCED: 110dB (IHF-A) / UNBALANCED: 110dB (IHF-A) CD: BALANCED: 98dB (IHF-A) / UNBALANCED: 98dB (IHF-A)
|
|
Signal to Noise Ratio (IHF-A)
|
Super Audio CD:BALANCED: 121 dB / UNBALANCED: 118 dB CD:BALANCED: 121 dB / UNBALANCED: 118 dB
|
|
THD+N
|
Super Audio CD: 0.0006% (1 kHz, 0 dB) / CD: 0.0015% (1 kHz, 0 dB)
|
|
Digital Input Terminal
|
Coaxial Digital x 1, Optical Digital x 1, USB-A x 2(Front/Rear), USB-B x1
|
|
Analogue Output Terminal
|
BALANCED x 1, UNBALANCED x 1 Support Variable Level Output
|
|
Digital output Terminal
|
Coaxial Digital x 1, Optical Digital x 1
|
|
System Port
|
System Control (Φ3.5 mm Jack)
|
|
Headphone Output
|
Yes(Φ6.3 mm, 110 mV, 32 Ω VOL MAX))
|
|
USB-A/ USB-B (back) Support Codex (WAV)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
USB-A/ USB-B (back) Support Codex (FLAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
USB-A/ USB-B (back) Support Codex (DSD)
|
Yes (2.8 MHz, 5.6 MHz, 11.2MHz)
|
|
USB-A/ USB-B (back) Support Codex (AIFF)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
USB-A/ USB-B (back) Support Codex (ALAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
USB-A/ USB-B (back) Support Codex (AAC)
|
Yes (32, 44.1, 48, 88.2, 96 kHz / 16-320 kbps)
|
|
USB-A/ USB-B (back) Support Codex (MP3)
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
Network Playback Support Codec (WAV)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
Network Playback Support Codec (FLAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
Network Playback Support Codec (DSD)
|
Yes (2.8 MHz, 5.6 MHz, 11.2 MHz)
|
|
Network Playback Support Codec (AIFF)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit)
|
|
Network Playback Support Codec (ALAC)
|
Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24 bit)
|
|
Network Playback Support Codec (AAC)
|
Yes (32, 44.1, 48, 88.2, 96 kHz / 16-320 kbps)
|
|
Network Playback Support Codec (MP3)
|
Yes (32, 44.1, 48 kHz / 16-320 kbps)
|
|
Ethernet Interface
|
LAN (100 Base-TX / 10 Base-T)
|
|
Wi-Fi
|
IEEE 802.11 a/b/g/n/ac, 2.4 GHz / 5 GHz Band
|
|
Bluetooth(Support codec)
|
Yes (AAC, SBC)
|
|
Power Supply
|
AC 220-240 V, 50 Hz / 60 Hz
|
|
Power Consumption/ Standby
|
45W/ 2W(Network Standby On)
|
|
Dimensions (W x H x D)
|
16.9 x 3.9 x 16 in
|
|
Weight
|
Approx. 27 lb
|
|
Accessories
|
Remote Control, AC Cord, System Connection Cable, Analogue Audio cable, Owner's Manual
|
